Hand/Peripheral Nerve

Vol. 3 - Issue 3 - December 2024

Insidious space of Parona infection complicated by acute compartment syndrome of the forearm in a diabetic young patient – Case report

Authors

Key words: space of Parona, acute compartment syndrome, suppurative tenosynovitis, forearm infection
Publication Date: 2024-12-18

Summary

Acute compartment syndrome of the forearm is an emergent surgical condition that is uncommonly associated with a suppurative tenosynovitis process, and its prompt identification and management is a must. However, the condition could have some pitfalls, especially when the progression of the infectious process is fast and rapidly extends to the forearm, mimicking a tromboflebitis or a fascitis.
We present a case of a 21 year-old diabetic man who suffered from a flexor tendon injury due to a hand cut, complicated with a suppurative tenosynovitis process and a space of Parona collection, presenting to the ER with a conclamate condition of acute compartment syndrome of the forearm.

INTRODUCTION

Acute compartment syndrome is an emergent surgical condition of increased pressure in a contained fibro-osseous compartment, leading to impaired perfusion pressure and subsequent neuro-muscular hypoxia or ischemia. The typical scenario for acute compartment syndrome involves upper limb fractures or crush injuries, but also burns, prolonged limb compression, and infections can be associated 1,2.

Irreversible tissue necrosis may occur if ischemia is not treated for more than eight hours, leading to serious limb-threatening complications such as deformity, paralysis, and amputation 3.

The diagnosis of a compartment syndrome highly relies on suspicion and clinical findings, like pain out of proportion, paresthesia, and paralysis of the involved muscles, while pulselessness is actually a late finding 2,4,5. However, the diagnostic path can have some “shades of gray” in case of an acute compartment syndrome caused by forearm suppurative process, as the pain out-of-control and the functional deficits can be equally shared between infectious cytotoxicity and intra-compartment vascular impairment. Furthermore, the scenario turns into “pitch dark” if the infectious process skips the common evolution of a flexor tenosynovitis, in which typically the pathogen advances from the wound site through the finger flexor sheet up to the muscle belly.

In this regard, we report a case of a forearm compartment syndrome, due to a primary Parona space suppurative expansion, as a complication of a Verdan Zone 2 hand cut, in which a methicillin-sensitive Staphylococcus aureus (MSSA) skipped digital channel by flowing through the tendon sheath up to the distal forearm 6.

CASE REPORT

A 21-year-old man, with a past medical history including tobacco habit and diabetes mellitus type I, poorly controlled through a subcutaneous insulin infusion pump, presented to the ER with a 5-day history of right hand cut in Verdan zone 2 at his fourth and fifth digits, accidentally inflicted with a knife while cleaning meat in a butchery. After abundant washing of the wound, which appeared completely free of any signs of infective process, he was admitted to the OR and underwent a four-strand flexor digitorum profundus repair for the fourth digit and flexor profundus reinsertion through a pull-out button plus radial collateral nerve suture for the fifth digit. A dorsal arm-cast in standard position was placed to protect the tendon sutures. Tetanus and antibiotic prophylaxis (Cefazolin 2g iv) were administered prior to the surgery, and oral Amoxicillin-Clavulanate 875+125 mg twice a day had been prescribed for the following five days.

He presented back to the outpatients only two weeks after the discharge, with a 48-hour history of progressive pain and swelling, that was initially noted in the hypotenar space and had progressed to involve the distal volar forearm. At presentation, he was febrile at 38°C, with tachycardia and hyperglycemia. Clinical examination revealed that the forearm was extremely edematous, warm and tense to palpation, revealing a decreased global sensation with intense paresthesia in median nerve territory. However, among the four Kanavel’s signs of pyogenic flexor tenosynovitis, only a slight flexion position of the digits and severe pain with passive finger extension were clearly appreciable 7,8. Patchy erythema was evident over the volar forearm and over the dorsum of the hand. The peripheral pulses were faintly palpable, and the distal capillary refill was over 3 seconds, as well as the pain worsening by elevating the limb and attempting passive finger extension. Laboratory findings revealed leukocytosis with neutrophilia (white blood cell count of 14.10 x 109/L, neutrophils 83.5%) and elevated C-reactive protein values of 302.77 mg/L.

An infectious process complicated by an acute compartment syndrome was postulated. The initial differential diagnosis included cellulitis and upper limb deep vein thrombophlebitis. A CT scan with contrast was performed, and upper limb vascular axis were shown pervious, while a fluid collection was appreciated within the middle and distal third of the volar forearm, without signs of gas formation.

Under general anesthesia, emergency fasciotomy and decompression of the volar compartments of the forearm were accomplished through an extensive approach, starting from a Z-shape midpalmar incision, gathered with the previous Brunnel-shape surgical wounds along fourth and fifth finger, across the carpal tunnel with transverse carpal ligament release, and extending longitudinally towards the cubital fossa. Immediate flexor muscles herniation was appreciated after a complete antebrachial fascia release, and almost 25 cc of pus collection poured out of the space of Parona, both extending into the midpalmar space of the hand and infiltrating within the deep flexor musculature of the forearm, causing loss of muscle definition. Conversely, the flexor sheaths of the fourth and fifth finger appeared spared of the suppurative process.

The pus collection was abundantly washed out with 5 L standard 0.9% isotonic saline solution, and soft tissue samples were taken for microbiology.

The median nerve appeared compressed distally by the pus collection and proximally by the oedema in the musculature, so an external neurolysis was performed. The dorsum of the hand was decompressed by a double dorsal fasciotomy. Wounds were left open, just loosely approximated, for further inspection (Fig. 1). The fasciotomy sites were covered with moist gauze, and a long dorsal arm slab was applied, placing the fingers in an intrinsic plus position.

Post fasciotomy, distal capillary refill returned to less than 3 seconds and pulses were clearly felt at the wrist.

An MSSA was isolated from the intra-operative specimens at the space of Parona, and a broad-spectrum antimicrobial therapy against Gram-positive cocci was started.

Two days after the initial debridement, the detection of a mottling and swelling along the medial surface of the arm led to an ultrasound investigation, which revealed a cellulitis process of the distal third of the medial arm. A second debridement procedure was promptly performed, by extending the previous surgical incision up to the medial side of the distal arm, with a rich cellulitis serous fluid drainage (Fig. 2).

The patient returned to the OR two more times, for further profuse wound irrigation and soft tissue debridement, and progressively the fasciotomy margins had been approximated by using vascular loops in order to facilitate the following coverage procedure 9.

Clinical conditions gradually improved, up to negative infection markers.

Two weeks after the first surgery, he underwent a volar forearm reconstruction surgery by closing directly the fasciotomy site of the hand and the proximal and middle forearm and by covering the distal forearm defect with a suine dermal substitute – Pelnac – (Fig. 3). After three weeks, the silicon external layer of the dermal substitute was removed and a split-thickness skin graft was placed (Fig. 4).

Following the complete adhesion of the skin graft, he experienced a pretty recovery throughout undergoing an extensive rehabilitation program to improve his functional outcomes (Fig. 5). Despite a valid restoration of wrist movements and fair finger extension, as well as of hand sensitivity, a severe grip strength deficit persisted over the follow-up period of four months 10. Both the flexor digitorum profundus and the flexor pollicis longus had been severely compromised by the intra-compartment ischemia and the infectious myotoxicity.

The patient had been scheduled for a delayed tendon transfer of brachioradialis pro-flexor pollicis longus and extensor carpi radialis brevis pro-flexor digitorum profundus.

DISCUSSION

The space of Parona, which was first described by the Italian anatomist Francesco Parona in 1876, extends from the proximal margin of the carpal tunnel to the mid-forearm 11. The roof is formed distally by the flexor digitorum profundus tendon and proximally by the belly of the flexor digitorum superficially; the ground is represented by the pronator quadratus distally and the interosseous membrane in the proximal two-thirds. The origin of the flexor digitorum superficialis forms the proximal boundary of this space, which is limited medially by the flexor carpi ulnaris and laterally by the flexor pollicis longus 12.

In 85% of people, Parona’s space serves as a communication between the radial and ulnar bursae at the level of the transverse carpal ligament and with the deep midpalmar space of the hand through the carpal tunnel 13. Typically, Parona’s space infections are secondary to suppurative flexor tenosynovitis through direct spreading or throughout the bursae.

No specific clinical test describes clearly an infectious process within the space of Parona. Swelling, tenderness, and occasionally fluctuance of the distal volar forearm are part of the clinical presentation of a Parona space infection, generally combined with loss of normal palmar concavity in cases of mid-palmar space purulent collection 14.

Furthermore, the formation of a suppurative collection within the forearm space increases the compartmental pressure, which in turn facilitates the spreading of the infection by reducing soft tissue perfusion. The noxious process could evolve till a stage of acute compartment syndrome, which occurs when raised pressure within a closed osteofascial compartment compromises the circulation and function of soft tissue in that body district 1.

Actually, the forearm is the most common site for compartment syndrome in the upper extremity. Despite the fact that a forearm compartment syndrome is not a rare clinical event, the triggering pathogenic process is uncommonly pyogenic flexor tenosynovitis 15-17.

In the specific clinical case, the pathogenetic hypothesis that has been postulated consists of a primary bacteria inoculation through the hand cut and flexor tendons involvement, trauma that happened in a potentially unclean working environment (a butchery), with a subclinical infection process. Despite the right therapeutical approach adopted during the first surgery, consisting of abundant irrigation of the wound and antibiotic prophylaxis, the diabetic comorbidity had progressively helped the bacteria proliferation into the undermined land and indolent dissemination through the synovial sheaths up to the space of Parona, causing micro-thrombosis, tissue necrosis and ending up in abscess formation. The blood flow impairment, depending on the intra-compartment pressure increase because of progressive purulent material accumulation, had subsequently promoted the infection spread by causing ischemia and further tissue necrosis towards pathways of decreased resistance. Finally, the microorganisms had also spread through the lymphatics to more proximal soft tissues, causing internal arm cellulitis.

The most frequent cause of septic tenosynovitis, complicated by acute compartment syndrome, is poor initial care and delayed presentation, events that had both happened in the case reported 18. Jointly, the diabetes mellitus type I, poorly controlled through a subcutaneous insulin infusion pump, had influenced both the timing and the severity of the clinical presentation 19 21. Moreover, the smoking habits of the patient could have played an additional role in the septic process and compartment syndrome, through microthrombosis and inflammatory triggering. Actually, both diabetes mellitus and tobacco have been studied as independent risk factors for infectious flexor tenosynovitis, and risk-adjusted prognostic scoring system for surgical wound infectious complications have been published 22-24.

With regard to the pathogen, a MSSA was identified, through culture tests, as to say the most common human pathogen for community soft tissue infection (Fig. 5) 25,26. Actually, 30 to 80% of hand infections can be attributed to gram-positive cocci, which can also be generally identified in the skin flora, followed by gram-negative bacilli, coagulase-negative staphylococci, Enterococcus species, and Escherichia coli 27-30.

An extended hand and forearm fasciotomy and accurate debridement are globally considered the standard of care in this scenario. The skin flaps could be left open, waiting for secondary reepithelialization, or could be progressively approximated along with the second-look procedures, up to a complete skin suture. In cases of residual “loss of substance” of the epithelial apparatus, a direct full-thickness skin graft can be considered as well as a dermal substitute, followed by a secondary split-thickness graft 31,32. In the reported case, it was chosen to cover the distal third of the volar forearm with the suine-derived artificial dermal substitute “Pelnac”, a two-layer structure which collagen scaffold, followed by an autologous split-thickness skin graft, after three weeks 33,34.

In the six-month follow-up, the patient presented with no pain, no sensory abnormality, and sufficient hand function for daily activities, despite the inability in grip and pinch strength. The range of passive movement and sensibility were improved significantly, as it was about the same as the unaffected hand at that time 35. However, according to Tsuge classification, the functional impairment that the patient reported can be described as a moderate type, including contracture of the FDP and FPL with variable findings of the FDS, FCU, and FCR 36.

In order to improve the functional outcomes of the young patient, he had been scheduled for a tendon transfer procedure of brachioradialis pro-flexor pollicis longus and extensor carpi radialis brevis pro-flexor digitorum profundus 37-39.

At the end of this resume, we can state that satisfactory results have been reached after a combination of timely surgical intervention and appropriate medical treatment, as part of a limb-salvage approach.

CONCLUSIONS

It is of utmost importance to suspect an acute compartment syndrome caused by infectious tenosynovitis in similar scenarios, where penetrating injury insidiously progresses from a hand cut and poses a serious threat to the limb. We believe that early diagnosis and aggressive treatment, including administration of antibiotics, early fasciotomy, and debridement of all necrotic tissue, have saved the life and the limb to our patient.

Acknowledgements

The authors thank the nurse staff of the Hand Surgery Department for the assistance given to the data collection.

Conflict of interest statement

The authors declare no conflict of interest.

Funding

This research did not receive any specific grant from funding agencies in the public, commercial, or not-forprofit sectors.

Author contributions

MP: A, D, DT, S, W

DP: DT

AL: DT

Abbreviations

A: conceived and designed the analysis

D: collected the data

DT: contributed data or analysis tool

S: performed the analysis

W: wrote the paper

O: other contribution (specify contribution in more detail)

Ethical consideration

The study was conducted ethically, with all study procedures being performed in accordance with the requirements of the World Medical Association’s Declaration of Helsinki. Written informed consent was obtained from the patient for study participation and data publication.

History

Received: October 27, 2024

Accepted: November 24, 2024

Published online: December 18, 2024

Figures and tables

Figure 1. Decompression of the volar forearm compartment through a longitudinal incision, starting from the midpalmar space, across the carpal tunnel and extending proximally along the forearm towards the cubital fossa.

Figure 2. Extension of the previous surgical incision up to the medial side of the distal arm.

Figure 3. A,B) Two weeks after the first surgery, the fasciotomy wound was sutured both at the palm and at the proximal and middle forearm, while the remaining distal forearm defect was covered with a suine dermal substitute «Pelnac»; C) Wound aspect three weeks later.

Figure 4. A) Three weeks after Pelnac implant, the silicon external layer was removed and a split-thickness skin graft was placed; B) Appearence of the skin graft, two weeks later.

Figure 5. Functional outcomes after two months of rehabilitation: valid restoration of wrist movements and fair finger extension, but still an important grip strength deficit, due to the severe compromission of the flexor digitorum profundus and the flexor pollicis longus.

References

  1. Taylor J, Wojcik A. Upper limb compartment syndrome secondary to streptococcus pyogenes (Group A streptococcus) infection. J Surg Case Rep 2011;2011:3. https://doi.org/10.1093/jscr/2011.3.3
  2. Mortensen SJ, Vora MM, Mohamadi A, et al. Diagnostic modalities for acute compartment syndrome of the extremities: a systematic review. JAMA Surg 2019;154:655-665. https://doi.org/10.1001/jamasurg.2019.1050
  3. Yeşil M, Özcan Ö, Karasu N, et al. Atypical compartment syndrome of the forearm due to mixed infection with Proteus mirabilis and Morganella morganii after a penetrating injury: a limb-saving approach. Jt Dis Relat Surg 2023;34:752-756. https://doi.org/10.52312/jdrs.2023.1066
  4. Miranda-Klein J, Howell CM, Davis-Cheshire M. Recognizing and managing upper extremity compartment syndrome. JAAPA 2020;33:15-20. https://doi.org/10.1097/01.JAA.0000660124.51074.e5
  5. Shiraz A, Bakhtiar H, Farman G, et al. Unidentified recurrent acute compartment syndrome of the right upper limb. Cureus 2022;14:E22033. https://doi.org/10.7759/cureus.22033
  6. Tropet Y, Menez D, Dreyfus-Schmidt G, et al. Recent simple flexor tendon injuries in zone I, II, III of Verdan. Results of tendon repairs concerning 115 fingers in 99 patients. Ann Chir Main 1988;7:109-114. https://doi.org/10.1016/s0753-9053(88)80045-0
  7. Kennedy CD, Huang JI, Hanel DP. In brief: Kanavel’s signs and pyogenic flexor tenosynovitis. Clin Orthop Relat Res 2016;474:280-284. https://doi.org/10.1007/s11999-015-4367-x
  8. Hyatt BT, Bagg MR. Flexor tenosynovitis. Orthop Clin North Am 2017;48:217-227. https://doi.org/10.1016/j.ocl.2016.12.010
  9. Raff AB, Kroshinsky D. Cellulitis: a review. JAMA 2016;316:325-337. https://doi.org/10.1001/jama.2016.8825
  10. Williams DW, Dyer GSM, von Keudell A, et al. Characteristics and outcomes of patients who undergo fasciotomies for upper arm compartment syndrome. Eur J Orthop Surg Traumatol 2023;33:2291-2296. https://doi.org/10.1007/s00590-022-03416-7
  11. Shin EK, Meals RA. The historical importance of the hand in advancing the study of human anatomy. J Hand Surg Am 2005;30:209-221. https://doi.org/10.1016/j.jhsa.2004.09.004
  12. Jamil W, Khan I, Robinson P, et al. Acute compartment syndrome of the forearm secondary to infection within the space of Parona. Orthopedics 2011;34:E584-E587. https://doi.org/10.3928/01477447-20110714-18
  13. Sharma KS, Rao K, Hobson MI. Space of Parona infections: experience in management and outcomes in a regional hand centre. J Plast Reconstr Aesthet Surg 2013;66:968-972. https://doi.org/10.1016/j.bjps.2013.03.020
  14. Lui TH, Lee CH. Little Finger flexor tendoscopy, endoscopy of the ulnar bursa and midpalmar space. Arthrosc Tech 2018;7:E817-E822. https://doi.org/10.1016/j.eats.2018.04.002
  15. Khoshhal KI, Alsaygh EF, Alsaedi OF, et al. Etiology of trauma-related acute compartment syndrome of the forearm: a systematic review. J Orthop Surg Res 2022;17:342. https://doi.org/10.1186/s13018-022-03234-x
  16. Ogrodnik J, Oliver JD, Cani D, et al. Clinical case of acute non-traumatic hand compartment syndrome and systematic review for the upper extremity. Hand (N Y) 2021;16:285-291. https://doi.org/10.1177/1558944719856106
  17. Robinson CA, Kellar JZ, Stehr RC. An 84-year-old man with acute atraumatic compartment syndrome of the upper extremity due to Streptococcus pyogenes cellulitis. Am J Case Rep 2021;22:E929176. https://doi.org/10.12659/AJCR.929176
  18. McDonald LS, Bavaro MF, Hofmeister EP, et al. Hand infections. J Hand Surg Am 2011;36:1403-1412. https://doi.org/10.1016/j.jhsa.2011.05.035
  19. Sharma K, Pan D, Friedman J, et al. Quantifying the effect of diabetes on surgical hand and forearm infections. J Hand Surg Am 2018;43:105-114. https://doi.org/10.1016/j.jhsa.2017.11.003
  20. Luginbuhl J, Solarz MK. Complications of Hand Infections. Hand Clin 2020;36:361-367. https://doi.org/10.1016/j.hcl.2020.03.010
  21. Hayden AJ, Shah NV, Stroud SG, et al. Characterizing hand infections in an underserved population: the role of diabetic status in antibiotic choice and infection location. J Hand Microsurg 2020;12:13-18. https://doi.org/10.1055/s-0039-1692323
  22. Bryant BSH, Marsh K, Smithson IR, et al. Patient risk factors associated with postoperative complications after common hand procedures. Hand (N Y) 2022;17:993-998. https://doi.org/10.1177/1558944720988102
  23. Stewart CN, Ward CM. Infectious flexor tenosynovitis following trigger finger release: incidence and risk factors. Hand (N Y) 2022;17:529-533. https://doi.org/10.1177/1558944720930298
  24. Eberlin KR, Ring D. Infection after hand surgery. Hand Clin 2015;31:355-360. https://doi.org/10.1016/j.hcl.2014.12.007
  25. Kistler JM, Thoder JJ, Ilyas AM. MRSA Incidence and antibiotic trends in urban hand infections: a 10-year longitudinal study. Hand (N Y) 2019;14:449-454. https://doi.org/10.1177/1558944717750921
  26. Fowler JR, Ilyas AM. Epidemiology of adult acute hand infections at an urban medical center. J Hand Surg Am 2013;38:1189-1193. https://doi.org/10.1016/j.jhsa.2013.03.013
  27. Benito N, Franco M, Coll P, et al. Etiology of surgical site infections after primary total joint arthroplasties. J Orthop Res 2014;32:633-637. https://doi.org/10.1002/jor.22581
  28. Malizos KN, Papadopoulou ZK, Ziogkou AN, et al. Infections of deep hand and wrist compartments. Microorganisms 2020;8:838. https://doi.org/10.3390/microorganisms8060838
  29. Patel DB, Emmanuel NB, Stevanovic MV, et al. Hand infections: anatomy, types and spread of infection, imaging findings, and treatment options. Radiographics 2014;34:1968-1986. https://doi.org/10.1148/rg.347130101
  30. Lovero S, Marchica P, Romeo M, et al. Clostridium septicum fasciitis in a patient with occult colon malignancy: a case report and literature review. PRRS 2022;1:69-75. https://doi.org/10.57604/PRRS-084
  31. Kakagia D. How to close a limb fasciotomy wound: an overview of current techniques. Int J Low Extrem Wounds 2015;14:268-276. https://doi.org/10.1177/1534734614550310
  32. Kistler JM, Ilyas AM, Thoder JJ. Forearm compartment syndrome: evaluation and management. Hand Clin 2018;34:53-60. https://doi.org/10.1016/j.hcl.2017.09.006
  33. Rehim SA, Singhal M, Chung KC. Dermal skin substitutes for upper limb reconstruction: current status, indications, and contraindications. Hand Clin 2014;30:239-252, vii. https://doi.org/10.1016/j.hcl.2014.02.001
  34. Scuderi N, Fioramonti P, Fanelli B, et al. The use of dermal regeneration template (Pelnac®) in a complex upper limb trauma: the first Italian case report. Eur Rev Med Pharmacol Sci 2019;23:5531-5534. https://doi.org/10.26355/eurrev_201907_18285
  35. Sharma P, Swamy MK. Results of the Max Page muscle sliding operation for the treatment of Volkmann’s ischemic contracture of the forearm. J Orthop Traumatol 2012;13:189-196. https://doi.org/10.1007/s10195-012-0212-0
  36. Stevanovic M, Sharpe FE. Refinements in the treatment of Volkmann ischemic contracture of the forearm: a thematic review. Plast Reconstr Surg Glob Open 2024;12:E5532. https://doi.org/10.1097/GOX.0000000000005532
  37. Isaacs J, Ugwu-Oju O. High median nerve injuries. Hand Clin 2016;32:339-348. https://doi.org/10.1016/j.hcl.2016.03.004
  38. Jones NF, Machado GR. Tendon transfers for radial, median, and ulnar nerve injuries: current surgical techniques. Clin Plast Surg 2011;38:621-642. https://doi.org/10.1016/j.cps.2011.07.002
  39. Ratner JA, Peljovich A, Kozin SH. Update on tendon transfers for peripheral nerve injuries. J Hand Surg Am 2010;35:1371-1381. https://doi.org/10.1016/j.jhsa.2010.05.023
